Automation for hinged doors with one or two doors,
for continuous and intensive use, conceived for public offices,
hospitals and nursing homes. The range has a compact design,
and is available in two different models: ARIA (motor opening
and closing) and ARIA S (motor opening and spring closing).
The automation can be set in "low energy" or "full energy"
operation mode.
| TECHNICAL DATA |
ARIA |
ARIA S |
| power supply |
full range 100÷240 Vac | 50/60 Hz |
full range 100÷240 Vac | 50/60 Hz |
| absorption |
70 W |
70 W |
| power consumption in stand-by |
3 W |
3 W |
| accessories power supply |
24 Vdc = / 1 A max |
24 Vdc = / 1 A max |
| opening time |
1,5÷8 s / 90° |
1,5÷10 s / 90° |
| closing time |
1,5÷8 s / 90° |
1,5÷10 s / 90° |
| maximum torque |
45 Nm |
28 Nm (opening) 18 Nm (closing) |
| operation type |
motor opening | motor closing |
motor opening | spring closing |
| type and frequency of use |
continuous operation = 100% |
continuous operation = 100% |
| operating temperature |
-15℃ / +50℃ |
-15℃ / +50℃ |
| protection degree |
IP31 |
IP31 |
| memory for saving data
and door regulation settings |
USB port |
USB port |
